Frame and sash side hinge in extruded aluminium, zamak plates, nylon bushings, screws, setscrew and pin in stainless steel. Maximum load 200 kg for casement opening.
Various materials. Backset 27 mm, latch version.
Handling and tips made of zamak; delrin offset devices; stainless steel screws and cams. Handling body plus top and lower terminal.
Made of zamak; pins and setscrews in stainless steel; connecting pins in galvanized steel; rod in extruded aluminium. For tilt and turn, with 12 mm connecting pins and insert plate.
Levers and pins in stainless steel, support and adjustment body in zamak. With short arm for tilt before turn. For right opening (doors from 470 to 600 mm). Maximum load 130 kg - 150 kg in combination with 3310.51 - 180 kg in combination with 3310.50+1211 (with limited opening 90°).
Levers and pins in stainless steel, support and adjustment body in zamak. With short arm for tilt before turn. For right opening (sashes from 601 to 1500 mm). Maximum load 130 kg - 150 kg in combination with 3310.51 - 180 kg in combination with 3310.50+1211 (with limited opening 90°).
Various materials. No frontal closure version. Backset 43 mm, interaxe 85 mm
Various materials. Backset 33 mm, Centre distance 92 mm
Various materials. Backset 43 mm, Centre distance 92 mm
Various materials. Backset 43 mm, Centre distance 85 mm
Various materials. Backset 33 mm, Centre distance 85 mm
Handle, case, inserts and frame in zamak; zinc-plated steel screws; stainless steel springs; nylon caps. Version with handle rotation at 180°. Pin protrusion 21.5 mm. Suitable for systems with sash section from 30 to 45 mm. Machining 136x24.
