Extruded aluminium body hinge; Zamak lever; steel spring; Nylon anti-friction plate. Block version for horizontal pivot, Load max 120 kg .
Extruded aluminium body hinge; Nylon anti-friction plate. Version without block for vertical pivot, Load max 80 kg.
Bushing in nylon; zamak interaxis reducer, stainless steel screws. Fixing screws L 26 mm
Die-cast aluminum handle, nylon bushing, zama case, stainless steel grain and springs, galvanized steel pin. Pin protrusion 26mm
Hinge and plate in extruded aluminum, plates frame side, pin, eccentric height regulator, screws, cams and stainless steel rains; adjustment pawl in zamak; bush and adjustment bases in nylon. Load 120 kg
Hinge and plate in extruded aluminum, plates frame side, pin, eccentric height regulator, screws, cams and stainless steel rains; adjustment pawl in zamak; bush and adjustment bases in nylon. Load 140 kg
Hinge and plate in extruded aluminum, plates frame side, pin, eccentric height regulator, screws, cams and stainless steel rains; adjustment pawl in zamak; bush and adjustment bases in nylon. Load 160 kg
Lever and rods in stainless steel, support and adjustment body in zamak. Top hinge for casement. For Right opening. Maximum load 130 kg - 150 kg in combination with 3310.51 - 180 kg in combination with 3310.50+1211 (with limited opening 90°).
Levers, pins, cams, and frame angle support in stainless steel, adjustment body in zamak. With short arm for tilt and turn. For right opening (sashes from 470 to 600 mm). Maximum load 100 kg - 130 kg in combination with 3310.51 - 150 kg in combination with 3310.50+1211 (with limited opening 90°). Adaptable to coplanar profiles up to a 12 mm step.
